“Keyboard shortcuts” dialog box

Tools: Shortcuts

The area on the left side of the Keyboard Shortcuts dialog box lists the task areas; the area on the right side lists the tools of each task area.

Note: You can see all tools of all task areas, including tools that are not activated in your current Allplan version. Inactive tools have semitransparent symbols.

You can use the Up arrow, Down arrow keys and the Page up, Page down keys to switch between the task areas in the list on the left side. To go to a specific task area, click in the list on the left side and enter the first letter of the required task area. The area on the right side lists the tools in the selected task area and the shortcuts assigned.

You can find general tools without icons or tools that do not belong to a task area in the More tools or More tools without icons group in the list on the left side.

The upper area of the Keyboard Shortcuts dialog box provides a Search box. You can use this box to find tools across task areas.

When the table on the right side shows the tool to which you want to assign a keyboard shortcut or of which you want to change the existing keyboard shortcut, click in this line in the Shortcuts column and enter the required keyboard shortcut. If this keyboard shortcut is already in use, you will see a message.

Note: You can also assign keyboard shortcuts by means of Customize User Interface... - Customize dialog box - Customize tab.

Buttons in the dialog box

Export

Exports the defined keyboard shortcuts as a *.shc file to any folder.

Import

Imports keyboard shortcuts saved as a *.shc file.

Reset

Restores the default settings of Allplan by resetting all keyboard shortcuts you defined yourself and all changes you made to predefined keyboard shortcuts.

Save

Saves all keyboard shortcuts defined in the Keyboard Shortcuts dialog box as user-specific settings to the registry.

Cancel

If you have made changes in the Keyboard Shortcuts dialog box, you can see a prompt.
Click Yes to save the changes. This is equivalent to clicking the Save button.
Click No to discard all changes. The Keyboard Shortcuts dialog box closes. You are back in Allplan.
When you Cancel the prompt, you are back in the Keyboard Shortcuts dialog box.

Tip: The Shortcut Keys tool lists all keyboard shortcuts assigned. You can also print this list.
